| P/N | P313AP Pyramid Adapter | P313AL KD Adapter |
|---|---|---|
| Weight Limit | 55 kg / 121 lb | 55 kg / 121 lb |
| Build Height | 83 mm | 82 mm |
| Knee Center to Top | 20 mm | 19 mm |
| Product Weight | 415 g | 436 g |
| Pylon Size | 22 mm | 22 mm |
| Material | Aluminum | Aluminum |
| Warranty | 1 year | 1 year |
| P/N | Description |
| LY13 | Lanyard for Manual Locking Knee for P313 |
| PA31 | AK Pyramid Adapter, P313A/P317A |
| KA31 | KD Knee Disartic Adapter, P313A/P317A |
| P211A | Tube Clamp Assembly |
| P231A | SACH Foot Adapter |
| P220A | 4 Ear Connector |
| P245S | 22 mm Tube Clamp with Standard Receiver, SS |
| Fastener | Torque | Wrench |
|---|---|---|
| M6 Cap Screw | 7 Nm | 5 mm Hex |
KD / Pyramid Bolt | 21.5 Nm | 6 mm Hex |
Instructions for Use (IFU)
