Size | MOTION STEP K3 Weight Limit – 80kg - 100kg 176 lbs to 220 lbs | MOTION STEP K2 Weight Limit – 100kg – 125kg 220 lbs – 275 lbs |
22 Left | 1109-22L-220 | 1109-22L-275 |
22 Right | 1109-22R-220 | 1109-22R-275 |
23 Left | 1109-23L-220 | 1109-23L-275 |
23 Right | 1109-23R-220 | 1109-23R-275 |
24 Left | 1109-24L-220 | 1109-24L-275 |
24 Right | 1109-24R-220 | 1109-24R-275 |
25 Left | 1109-25L-220 | 1109-25L-275 |
25 Right | 1109-25R-220 | 1109-25R-275 |
26 Left | 1109-26L-220 | 1109-26L-275 |
26 Right | 1109-26R-220 | 1109-26R-275 |
27 Left | 1109-27L-220 | 1109-27L-275 |
27 Right | 1109-27R-220 | 1109-27R-275 |
| P/N | Description |
|---|---|
| 1109SNB-Y | Replacement Rubber Ring, Yellow |
| 1109SNB-B | Replacement Rubber Ring, Blue |
| Fastener | Torque | Hex |
|---|---|---|
| Foot Bolt | 30 Nm | 8 mm Hex Wrench |
Instructions for Use (IFU)
PDAC Letter
Product Information
